GENERAL SPECIFICATIONS The settings are made easily from the PLC-controlled touch screen. Mechanical settings are simple to use and easy to learn. Information on usage can be stored in memory and used continuously. Daily cleaning is easy. It is easy to disassemble, install and replace belts and running parts. The speeds of all belts can be adjusted to the desired level. Electrical and electronic faults that may occur are displayed on the PLC screen with pic and text. In case of malfunction, remote access can be performed with PLC program (Optional)
Since very little flour is used in the dough section, it provides a clean working environment. The amount of flour given to the cut dough can be adjusted. The lubrication system is automatically adjusted during the dough cutting process. Unlike other machines, it does not wear dough due to non-pressurized cutting. All parts in contact with the dough are made of stainless steel 304.
Note: Since there are pneumatic pistons on the machine, air of minimum 4 bar pressure is required for the operation of the machine. 5 * 2.5 multiple cables must be use for electricity. In order to prevent damage to the automation products used in the machine, a suitable regulator is recommended to prevent voltage fluctuations in electricity.
Division Range (Piston diameter) : 25-90 gr (Ø45 mm), 30-115 gr (Ø48 mm), 40–140gr (Ø 50 mm), 50–160gr (Ø 55 mm), 60–180gr (Ø 60 mm) and 70–220gr (Ø 65 mm).
| Model | number of Row | Capacity (pcs) | Dimension (WxLxH)/cm | Electric Power Kw | Voltage (V/Hz) | Weight |
|---|---|---|---|---|---|---|
| GLODA-6 | 6 | 11000 | 148x222x184 | 5 | 380V50 | 1700kg |
